3/4-16 RH Steel Housing, Steel Race 0.751 Bore

Free shipping on orders over $50 to the lower 48 states

$0.00

Part #: MSM-12

Brand: Steinjäger

MSM-12, Bearings, Spherical Rod End, Male, 3/4-16 RH, Steel Housing, Steel Race 0.751 Bore

Approximate Weight (lbs): 0.58

California Residents: WARNING

Out of Stock

Available Options

Overview

Reviews (0)

Bearings, Spherical Rod End Male 3/4-16 RH Steel Housing, Steel Race 0.751 Bore

Ball: low carbon steel, surface hardened for wear resistance and plated for corrosion resistance.

Configuration: housing and stud dimensions are subject to change based on manufacturing considerations.

Housing: low carbon steel, plated and dichromate treated for corrosion resistance.

Left Hand Thread: specify left hand housing threads by adding an "L" before the "-" (i.e., MSML-6).

Mounting Stud: an optional feature specified by adding an “S” after the nominal size (i.e., MSM-6S).

Race: the MSM-series features a close fit between the ball and the housing that allows the housing member itself to act as the bearing race.
