10-32 RH Steel Housing, Steel Race

Free shipping on orders over $50 to the lower 48 states

$0.00

Part #: MSF-3

Brand: Steinjäger

MSF-3, Bearings, Spherical Rod End, Female, 10-32 RH, Steel Housing, Steel Race

Approximate Weight (lbs): 0.03

California Residents: WARNING

Out of Stock

Available Options

Overview

Reviews (0)

Bearings, Spherical Rod End Female 10-32 RH Steel Housing, Steel Race

Construction: The MSF-series features a close fit between the ball and the low carbon steel housing that allows the housing member itself to act as the bearing race. The ball is low carbon steel, surface hardened for wear resistance and plated for corrosion resistance. The housing is plated and dichromate treated for corrosion resistance.

Mounting Stud: an optional feature specified by adding an "S" after the nominal size (i.e., MSF-6S), mounting studs are made from low carbon steel, and are plated and dichromate treated for corrosion resistance. Standard stud threads are right hand.
