Universal Rod Ends Inch Male Weldable Chrome Moly Housing, PTFE Race 1 Pack
Quantity Per Package: This package includes One Weldable Spherical Rod Ends
Product Name: Weldable Spherical Rod End
Ball ID: 1/2"
Housing Material: 4130 Heat Treated Chrome Moly Steel
Finish: Bright Chrome Plated, Weldable area is not plated
Ball Finish: Hard Chrome Plated
Bearing Race: Steel on Steel
Housing Width: 0.453"
Base of Rod End to Center of Ball: 2.438"
Ball Thickness: 0.625"
Insert Diameter: 0.855" (this is the diameter of part that goes inside the tube)
Insert Length: 0.625" (this is the length of part that goes inside the tube)
Body Diameter: 1.000"
Common Other Names for this Product: chromoly heim joint, rose joint
Application: Our larger chrome moly Spherical Rod Ends are used as sway bar end links, panhard bars, control arms, three link and four link suspensions and strut tower braces. This size rod end is often used in hand or foot actuated push-pull linkages.
Warning: Regardless of a specific product's name or marketing description, rod ends used in the wrong application will fail. We encourage our customers to know the load rating requirements of their application.
Comment: For the best safety results, make sure any welding is done by a certified welder, and that the mating components are of the same or comparable material.
